Single-phase wet & dry
S3B L50
Product number: 4010500037
Power, simplified
_MD-ps-Original-CLPPNF.webp?width=768&rxy=0.5%2c0.5&format=webp)
_MD-ps-Original-CLPPHJ.webp?width=768&rxy=0.5%2c0.5&format=webp)
_MD-ps-Original-CLPPNF.webp?width=768&height=768&rxy=0.5%2c0.5&format=webp)
_MD-ps-Original-CLPPHJ.webp?width=768&height=768&rxy=0.5%2c0.5&format=webp)
S3B L50
Reliability, power and simplicity for this industrial vacuum designed for the mechanical sector, in particular for the collection of chips mixed with oil.
Specifications for S3B L50
Voltage (V)230
Frequency (Hz)50-60
IP protection class43
Insulation classI
Rated power (kW)3
Airflow without hose (m³/h - l/m) 486 - 8100
Max. vacuum (kPa - mbar)21 - 210
Sound pressure level (dB(A))75
Container capacity (l)50
Main filter area (cm²)19500
Inlet (mm)70
Length x width x height (mm)795x600x1275
Weight (kg)67
Different variants of S3B L50
Below you can see the different variants of the product
CO2 emissions for “S3B L50”
Estimate your annual CO2 footprint based on weekly usage.
0 kg
CO2 per year
